質問 # 32
In the CloudFabric network service open programmable overall solution, which component is responsible for southbound interconnection with heterogeneous network devices?
- A. Business systems
- B. FabricInsight
- C. Runbook
- D. AOC
正解：D
解説：
Analysis: AOC is an open platform that can upload SND packages from corresponding vendors and support interconnection with third-party NEs.
質問 # 33
Which of the following hard disk media does not support the NVMe interface protocol in mainstream server scenarios?
- A. SCM
- B. SSD
- C. HDD
- D. DRAM
正解：C
解説：
Resolution: NVMe is a protocol used for high-speed storage.
質問 # 34
Which of the following descriptions of container technology and virtual machine technology is wrong?
- A. Containers don't need separate kernels
- B. Containers are more isolated than virtual machines
- C. Containers start up faster than virtual machines
- D. Container images are smaller than virtual machines
正解：B
質問 # 35
In an enterprise data center, the customer assigns a virtual firewall (VSYS1 and VSYS2) to the finance department (VPC1) and the sales department (VPC2), VSYS1 If it is located in the same ServiceLeaf as VSYS2, what are the correct descriptions of traffic orchestration in this scenario?
- A. Regardless of whether the Border Leaf and Service Leaf are co-located or separated, the traffic model is consistent
- B. In the scenario where the Border Leaf and Service Leaf are separated, the traffic between the VPC and the VPC needs to pass through the Border Leaf
- C. In the scenario where the Border Leaf and Service Leaf are separated, the controller will create VPC1 and VPC2 on the Service Leaf according to the VPC interoperability requirements Associated VRF
- D. The tenant needs to specify the interworking VRF on the controller to complete the VPC interworking in this scenario
正解：A、C
解説：
Analysis: A error, vsys1 and vsys2 are in the same service leaf, if they are in the same FW, they are interworking through fw, if they are in different ways fw, the interworking needs to be passed serviceleaf Nothing to do with borderleaf. B is correct, because the vsys appears on the fw that connects to the serviceleaf, there must be a docking vsys on the serviceleaf VRF, Change the VRF to belong to the corresponding VPC. C is incorrect, the tenant only needs to specify which pair of VPCs can communicate with each other on the controller, and does not need to consider how the underlying layer implements interoperability or specifies the interworking vrf. D is correct, in the scenario where the VPC is interconnected over the wall, two VSYS may fall on one FW, or they may fall on different FWs , the interoperability is only related to fw and serviceleaf, and has nothing to do with borderleaf. So the traffic model has nothing to do with how the border leaf is deployed.
質問 # 36
In a CloudFabric multi-computing lossless network, if a device wants to remove the PFC deadlock by not responding to a backpressure frame, which of the following lossless functions needs to be deployed?
- A. AI ECN
- B. PFC deadlock prevention
- C. DCQCN
- D. PFC deadlock detection
正解：B
質問 # 37
Which of the following layers does the CloudFabric cloud-network integration solution architecture consist of?
- A. Network service layer
- B. Network Analysis/Control Layer
- C. Business presentation layer/collaboration layer
- D. Storage access layer
正解：A、B、C
解説：
Parse:
質問 # 38
What are the correct terms of the following description of ECN high and low thresholds?
- A. When the queue cache is above the high threshold, all ECN tokens are performed
- B. When the queue cache falls below a low threshold, no ECN tagging is performed
- C. The queue cache is above the low threshold but below the high threshold, and the closer it is to the high threshold, the higher the probability of tagging
- D. If the queue cache is higher than the high threshold, all packets are discarded
正解：A、B
質問 # 39
In the CloudFabric cloud-network integration scenario, which of the following descriptions of secondary restore is incorrect?
- A. MDC cross-DC orchestration is not supported
- B. The service chain can be configured for secondary restoration
- C. After services delivered by the cloud platform are restored on iMaster NCE-Fabric, you can use the batch configuration function to perform batch secondary orchestration
- D. By default, VPC interconnection does not support communication between the same subnet under different routers
正解：A
解説：
Resolution: A is correct, please refer to the NCE-fabric manual. D Correct. OpenStack does not support business chain orchestration. B Correct. C is incorrect, MDC cross-DC business orchestration is supported.
質問 # 40
Which of the following components of open-source OpenStack provides a Dashboard for users to use?
- A. Keystone
- B. Heat
- C. Cinder
- D. Horizon
正解：D
質問 # 41
When service provisioning fails in the CloudFabric data center network, which of the following functions can be used to simulate service provisioning in iMaster NCE-Fabric to view specific problems
- A. Fault alarms
- B. Tenant snapshot rollback
- C. Service connectivity testing
- D. Business simulation
正解：D
質問 # 42
By default, iMaster NCE-FabricInsight can predict the interface traffic trend at which of the following times?
- A. 1 month
- B. 3 months
- C. 4 months
- D. 2 months
正解：B
質問 # 43
In Huawei's CloudFabric solution, if you want to use a third-party VAS device to provide value-added services, which of the following VAS device management modes should you use if the VAS device cannot be managed by the controller ? ?
- A. Network Manager
- B. Network Policy
- C. Service Policy
- D. Service Manager
正解：B
質問 # 44
Device configuration parameters can be adjusted when using the edge intelligence function of iMaster NCE-FabricInsight for specified stream analysis. Which of the following device configurations cannot be automatically delivered during UDP specified stream analysis?
- A. ACL Number
- B. Active aging time
- C. Whether the VXLAN packet is matched
- D. Whether to match TAG packets with a layer 1 VLAN
正解：B
質問 # 45
In a data center network, which of the following technologies can be used to achieve sub-second data collection?
- A. NETCONF
- B. RESTCONF
- C. Telemetry
- D. SNMP
正解：C
質問 # 46
Which of the following is a hypervisor among the basic concepts of computing virtualization technology?
- A. Guest Machine
- B. Hypervisor
- C. Guest OS
- D. Host OS
正解：B
質問 # 47
Which of the following lossless technologies can be deployed in an intelligent lossless data center network based on Huawei's CloudFabric solution?
- A. INOF
- B. PFC
- C. ECN
- D. IQCN
正解：A、B、C、D
解説：
Parse:
質問 # 48
For CloudFabric-based data center networks, you can use the iMaster NCE-Fabric controller and iMaster NCE-FabricInsight analyzer to provide refined O&M for the network. Which of the following is NOT an O&M feature provided by iMaster NCE-Fabric?
- A. Network health
- B. Three levels of rollback
- C. Service path detection
- D. Three-layer topology looks at each other
正解：A
解説：
Analysis: Network health analysis is a feature of FabricInsight. So the answer is A.
質問 # 49
Which of the following is Huawei's deep learning framework?
- A. CloudAI
- B. PyTorch
- C. MindSpore
- D. TensorFlow
正解：C
質問 # 50
In the open-source OpenStack business model, which of the following is the mapping between the Router and the Network?
- A. N:N
- B. 1:N
- C. N:1
- D. 1:1
正解：B
解説：
Resolution: The mapping between the router and the network is 1:N
質問 # 51
Data center networks usually use the Spine-Leaf architecture, in which VAS devices such as FW and LB are connected to the data center network through which of the following nodes?
- A. ServerLeaf
- B. Border Leaf
- C. Spine
- D. Service Leaf
正解：D
解説：
Analysis: Access through the Service Leaf device
質問 # 52
In the CloudFabric network virtualization scenario, which of the following interfaces does iMaster NCE-Fabric use to interconnect with the northbound system?
- A. NETCONF
- B. ERSPAN
- C. RESTful
- D. OpenFlow
正解：C
解説：
Parse:
質問 # 53
In the CloudFabric solution architecture, which of the following interfaces does the control layer interconnect with the application layer, receive the service instructions issued by the application layer, and return status information to the application layer?
- A. NETCONF
- B. RESTful/RPC
- C. SNMP
- D. OpenFlow
正解：B
解説：
Analysis: The application layer and the control layer communicate with each other through a RESTful interface.
質問 # 54
In the CloudFabric Cloud-Network Integration OpenStack scenario, a company wants the VMs created in the data center to be able to access the Internet Which of the following is the key content created on OpenStack?
- A. External Networks
- B. Business chain
- C. External gateways
- D. Security group
正解：A
質問 # 55
Which of the following descriptions of firewalls is wrong when deploying a data center network?
- A. After different security zones are divided on the firewall, the different security zones are isolated by default
- B. Firewalls can be deployed alongside Border Leaf to control secure access to incoming and outgoing traffic
- C. Firewalls can be deployed in active and standby image mode to enhance reliability
- D. The firewall can be managed through SecoManager, but the service needs to be configured manually
正解：D
解説：
Analysis: FW' s services can be automatically delivered through SecoManager
質問 # 56
......
